Applicable standard: GB18613 2020

Voltage: Low voltage

Full/semi dense: TEFC

Installation method: horizontal type - AEMB3N (F # 80M-315L), AFJN3N (F # 315A-355C) vertical type - AEMV3N (F # 80M-315L), AFJUF2 (F # 315A-355C)

Energy efficiency: GB3/IE3

Applicable conditions

1. Power supply conditions: voltage fluctuation rate within ± 10%, frequency fluctuation rate within ± 5%, comprehensive voltage and frequency fluctuation rate within ± 10%, and frequency fluctuation rate not exceeding ± 5%

2. Place of use: indoor, non hazardous gas environment

3. Ambient temperature: - 15~40 ℃

4. Ambient humidity: Relative humidity below 90% (but not condensing)

5. Altitude: below 1000m above sea level

6. Transmission mode: belt pulley transmission, but 2-pole 22kW and above, 4P&6P F # 280 and above use coupling transmission

7. Rotation direction: It can rotate in both directions. When the phase sequence of the power supply is consistent with the marking letters at the motor outlet end, it rotates counterclockwise when facing the shaft extension end

8. Starting method: full voltage direct starting or Y - △ starting, 4kw and below: Y; 5.5kw and above: △

9. Painting: Blue Munsell 5PB 3/8

10. Requirements: When installing a coupling or pulley, use the shaft end tap to press it in. It is prohibited to hit the shaft end with external force for installation

Motor characteristics

1. IP55 protective structure, dustproof, waterproof and oil foam, cast iron frame, strong structure, in line with international standards, more secure

2. Using Dongyuan Class F insulation, it has high heat resistance, strong resistance to electrical shock, and long insulation life, which can also be competent in harsh environments

3. The use of famous brand bearings and silicon steel sheets from famous steel mills provides more guaranteed performance

4. Standardized design, high-quality materials, advanced processing equipment, and a complete quality standard system are manifested in high efficiency, low vibration, low noise, and safety and reliability

5. Selection: According to customer needs, it can be equipped with thermal protector, PTC, space heater, RTD, PT100, and others

Product model: AEMB3N/AEMV3N

technical parameter

Power: 0.12kW~200kW

Number of poles: 2P~8P

Voltage: 380V or other voltages

Frequency: 50Hz or 60Hz

Frame No.: 63M~315L

Protection level: IP55

Insulation class: F

Product model: AFJN3N/AFJUF2

technical parameter

Power: 185kW~375kW

Number of poles: 2P~6P

Voltage: 380V or other voltages

Frequency: 50Hz or 60Hz

Box No.: 315A-355C

Protection level: IP55

Insulation class: F
